Sat-Lite Technologies 1231 1.2M Motorized Flyaway VSAT Terminal
Lightweight carbon fiber reflector, precision pedestal and feed design, simple pointing and peaking control, easily transportable, high RF gain
1231 1.2M Auto Deploy Flyaway
The Sat-Lite Technologies Model 1231 Agilis motorized carbon fiber flyaway antenna offers superior performance in a lightweight, portable package. This terminal features a four piece carbon fiber segmented reflector designed to provide high gain and low cross pol characteristics. The motorization package includes a ruggedized outdoor mounted controller with preconnectorized cables allowing for quick assembly and disassembly. The custom-designed elevation-over-azimuth tripod pedestal provides high stiffness with minimal weight. The antenna components are modular in design which also reduces assembly time and provides an improved packaging scheme requiring less time and effort to pack or unpack the antenna. The molded cases are included.
The Sat-Lite 1231 antenna is designed to meet international performance specifications for commercial or off-the-shelf military applications and is readily available in C, X, Ku and Ka band frequencies. Multiple feed and integration configurations are available
Features
Intelsat and Eutelsat Compliant
Multi-Band C-, X-, Ku- or Ka-band Capable
(4) Piece Segmented Carbon Fiber Reflector
Compact Pedestal featuring easy point and peak control
Ships in 2 Ruggedized Cases
High Gain / Low Cross Pol Design
Superior Stability in Wind
Multiple Integration Options
Excellent Reliability
Minimal Maintenance
Typical users include Federal and State emergency responders, Homeland Security, FEMA, Oil and Gas Industry, IP Based Communications, Broadcast SNG, Sporting Event Broadcasting, Critical Up-Linking, & Backup / Redundancy Communications
