Sat-Lite 1233 1.2M Motorized Quick Deploy Flyaway Terminal
Integrated Control System for 1 Button Auto Acquire, High Performance Motorization Package, Multi-Band Frequency Capable
1233 1.2M Motorized Portable VSAT Antenna
The Sat-Lite 1233 Celero motorized portable flyaway VSAT antenna is highly portable, compact, light-weight, and can be assembled by one person in less than 15 minutes. The antenna features a 2 or 4 piece segmented glass fiber reinforced reflector with compact pedestal and is designed to be value priced while providing exceptional performance in a lightweight package. The elevation-over-azimuth pedestal provides excellent stiffness characteristics and convenience for the user when pointing and peaking on a satellite. The antenna packs in 3 ruggedized shipping cases as standard configuration, other options are available.
In addition, the antenna is designed to meet International performance specifications for commercial or military applications. Multiple feed configurations and paint schemes are readily available. The control system is integrated within the unit. The full travel azimuth and elevation ranges allow the control system to provide true autolocate and peak options for the end user with simple 1 button operation.
Features
Intelsat Compliant
Multi-Band C, X, Ku band Frequencies
Multiple Integration Options
2 Axis Motorized Pedestal Configuration
Motorized Polarization For Linear Feeds
Full range of motion for Azimuth. Makes full use of auto-locate control options.
Excellent Reliability
Minimal Maintenance
Less than 15 min Assembly Time
Captive Hardware
Feedboom Mounted Integration with heavy payload
Designed to meet international performance specifications for commercial and/or military applications
