Sat-Lite 1832 1.8M Motorized Flyaway Quick Deploy Antenna

1832 1.8M Motorized Fly-Away Antenna

The Sat-Lite 1832 Celero 1.8 meter Motorized Flyaway Antenna offers excellent performance for a high value package. This antenna is specifically designed to provide a lower cost alternative for autolocate system requirements. A manual (non-motorized) antenna configuration can be supplied with autolocate assistance through the use of a customer furnished web browser. This option allows the un-trained user to easily position and peak the antenna on the satellite without the requirement of a fully motorized system. Alternatively, a fully motorized system can be provided to offer the same result at the push of a button. A ruggedized outdoor mounted controller, motorized azimuth hub assembly, and motorized elevation jack assembly are used in the fully motorized configuration.

Both manual and motorized systems are designed specifically for lower power VSAT applications using a BUC and a modem. Other options are available as well. The system is also offered with integrated feed boom assemblies that can pack in a case. Each assembly can include the feed, BUC, LNB and interfacing waveguide. The antenna meets international performance specifications for commercial applications and is readily available in C, X, and Ku band frequencies.

Features

 Intelsat Compliant

 Multi-Band C, X, Ku band Frequencies

 Multiple Integration Options

 2 Axis Motorized Pedestal Configuration

 Motorized Polarization For Linear Feeds

 Full range of motion for Azimuth. Makes full use of auto-locate control options.

 Excellent Reliability

 Minimal Maintenance

 Less than 15 min Assembly Time

 Captive Hardware

 Feedboom Mounted Integration with heavy payload
