Sat-Lite Technolgies 1021 1.0M Manual Acquisition Quick Deploy VSAT
Cost effective highly mobile satellite communications system, ideal for tactical and remote satcom applications
1021 1.0M Manual Acquisition Flyaway
The Sat-Lite Technologies Model 1021 flyaway antenna is highly portable, compact, light-weight, and can be assembled by one person in less than 15 minutes. The antenna features a 7 piece segmented carbon fiber composite reflector designed to provide exceptional performance in a lightweight package. The elevation-over-azimuth pedestal provides excellent stiffness characteristics and convenience for the user when pointing and peaking on a satellite. The antenna packs in 2 weatherized compression molded cases that meet the 62 inch rule for airline travel and are less than 32 Kg each.
In addition, this quick deploy antenna is designed to meet international performance specifications for commercial or military applications and is readily available in Ka-, Ku- and/or X-Band frequencies. Multiple feed configurations and paint schemes are readily available.
Features
Intelsat and Eutelsat Compliant
Multi-Band , X-, Ka-, or Ku-band Capable
(7) Piece Segmented Carbon Fiber Reflector
Compact Pedestal featuring easy point and peak control
Ships in three rugged transport cases
High Gain / Low Cross Pol Design
Superior Stability in Wind
Multiple Integration Options
Excellent Reliability
Minimal Maintenance

Typical users include Federal and State emergency responders, Homeland Security, FEMA, Oil and Gas Industry, IP Based Communications, Broadcast SNG, Sporting Event Broadcasting, Critical Up-Linking, & Backup / Redundancy Communications
