Winegard SPFx12A 1.2M Auto Acquire Motorized Flyaway Antenna

Sat-Lite Celero 1223 1.2 Meter Manual Flyaway Transportable VSAT Antenna System

AVL Technologies 1248K 1.2M Military Satcom Flyaway Antenna System

Be the first to review this product

SKU

Winegard-SPFx12A

Winegard SPFx12A 1.2M Auto Acquire Motorized Flyaway Antenna is available to buy in increments of 1

1.2 meter, 4 piece reflector, motorized with autopointing capability

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Winegard SPFx12A 1.2 Meter Flyaway Auto-Acquire System - Includes 1.2M Class II ASC SIGNAL 4 Piece Segmented Reflector, Tripod and Transportable cases, autopointing antenna controller, and all interconnect cabling. Staying connected, even in the most remote locations, has come to be expected in today’s fast paced, high tech global market place. And the new Winegard Airline Checkable Auto-Acquire Flyaway Antenna meets the ever growing need of having a real-time broadband solution in the most remote of locations when airline transportation is required.

Winegard Special Products Division antennas use the strongest, most rugged actuators and motors in the industry, allowing for maximum reliability in extreme environments as well as providing the fastest acquisition times in the market. The fully-integrated two-way controller features single-button operation without requiring an external PC. The Controller is rack-mountable, and the built-in DVB receiver and GPS makes the Winegard Two-Way Controller work on most platforms available in the industry including HughesNet, iDirect, SpaceNet, Comtech, and Nera.

Technical Specifications

GENERAL INFORMATION

Reflector Type _ _ _ _ _ _4 piece segmented 1.2 m .8 F/D Glass Fiber

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Reinforced Polyester SMC

Optics Offset _ _ _ _ _ _ _ _ _ _ Prime Focus Offset Feed

BUC Supported* _ _ _ _ _ _ _15 lbs. / 12” L x 7.75” W x 5.5” H

Polarization* _ _ _ _ _ _ _ _ _ _ _ _ _ Cross-pol

Mount Geometry _ _ _ _ _ _ _ _ _Elevation Over Azimuth

Set-up Time _ _ _ _ _ _ _ _ _ _ _ Less than 15 minutes

DIMENSIONS

Stowed Dimensions _ _ _ _ _ _ _ _ _ _ _ N/A

Max Deployed Height_ _ _ _ _ _ _ _ _ _ _ 70”
