Quintech Electronics Xtreme 32-C L-Band (Fan-In) RF Matrix Switch
Frequency range covers 950 MHz to 2150 MHz, 24x8, 16x16, and 28x4 L-band switching configurations available
Xtreme 32-C L-Band (Fan-In) RF Matrix
The Quintech Xtreme 32-C is a full fan-in (combining), non-blocking switch that combines one or more inputs to an output. This matrix switch supports both symmetric and asymmetric configurations of 32 combined outputs and inputs in an ultra compact 1RU chassis. The Xtreme 32-C features Hot-Swappable redundant power supplies, I/O Modules, and a field replaceable cooling fan that provides maximum reliability.
Features
-
32 Port Fan-in L-Band RF Matrix Switch
-
950-2150 MHz Operating Range
-
Compact design with a variety of configurations adding to 32 ports in 1 RU
-
Easisly hot-swappable power supplies
-
Independent input and output gain control
-
Remotely controlled via web browser GUI interface, SNMP, Telnet or TCP/IP via customer supplied PC
Typical full fan in and out matrix switch system shown here
Benefits
Q-ROUTE Provides Internal Signal Path Redundancy by Automatically Re-routing Around a Failed Signal Path
Q-SENSE Provides External Signal Path Redundancy by Automatic Switching of Back-up Input Signals
Content Delivery via Satellite, RF Matrix Switching Applications, supports both symmetric and asymmetric configurations of 32 combined inputs and outputs in a single chassis.
