Ku-Band Redundant LNA Plate Systems

At the heart of all Paradise Datacom Ku-Band redundant LNA systems are the field-proven low noise amplifier product lines. Available in all common Ku-Band frequencies, and offering state-of-the-art noise temperature performance, these LNAs can be configured for use in 1:1, 1:2 and custom redundant systems.

Easy Antenna Integration

System monitoring and control is provided through the microprocessor-based RCP2-1100 and RCP2-1200 redundant system controllers. LNA plate assemblies are designed for convenient integration into any antenna hub or facility with RF and user interfaces readily accessible.

Common feed interfaces are offered as standard and isolation is provided at all RF interfaces. A range of RF hardware options and custom plate configurations are offered to meet specific system requirements.

Features

Compact plate assemblies facilitate convenient antenna hub mounting

Standard feed orientations

State-of-the-art noise temperatures provided by Paradise Datacom LNAs

All LNAs contain integral RF isolators

CONTROL PANEL

User-friendly M&C provided locally as well as through a standard serial I/O. (RS-232, 485 or optional Ethernet interfaces)

Auto-ranging redundant power supplies: 85-264 VAC @ 47 to 63 Hz

High system level reliability

OPTIONS

LNA Redundant Systems

Transmit-band Reject Filter

Off-line RF I/O

Waveguide Test Inject Input Coupler

Coaxial Output Coupler

Custom LNA Plate Configurations

-48 VDC Operation

Remote Control Panels
