Teledyne Paradise Datacom C-Band Redundant LNA Plate Systems
Ultra Low noise figures, Complete LNA System Redundancy
C-Band Redundant LNA Plate Systems
At the heart of all Teledyne Paradise Datacom redundant LNA systems are the field-proven low noise amplifier product lines. Available in all common C-Band frequencies, and offering state-of-the-art noise temperature performance, these LNAs can be configured for use in 1:1, 1:2 and custom redundant systems.
Full Redundancy
System monitoring and control is provided through the microprocessor-based RCP2-1100 and RCP2-1200 redundant system controllers. LNA plate assemblies are designed for convenient integration into any antenna hub or facility with RF and user interfaces readily accessible.
Common feed interfaces are offered as standard and isolation is provided at all RF interfaces. A range of RF hardware options and custom plate configurations are offered to meet specific system requirements.
LNA Plate Features
Compact plate assemblies facilitate convenient antenna hub mounting
Standard feed orientations
State-of-the-art noise temperatures provided by Paradise Datacom LNAs
All LNAs contain integral RF isolators
CONTROL PANEL
User-friendly M&C provided locally as well as through a standard serial I/O. (RS-232, 485 or optional Ethernet interfaces)
Auto-ranging redundant power supplies: 85-264 VAC @ 47 to 63 Hz
High system level reliability
OPTIONS
LNA Redundant Systems
Transmit-band Reject Filter
Off-line RF I/O
Waveguide Test Inject Input Coupler
Coaxial Output Coupler
Custom LNA Plate Configurations
-48 VDC Operation
Remote Control Panels
Provides Complete C-Band LNA Redundancy in 1:1 and 1:2 System Configurations
