Be the first to review this product

$1,859.00

SKU

NST-9500HBCF

Norsat 9500HBCF Dual Ka-Band (19.2-21.2 GHz) PLL LNB F-Type ±50 kHz is available to buy in increments of 1

Dual Ka (19.2-21.2 GHz) PLL, F-Type 75 Ohm, Stability: ±50 kHz

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

9500HBCF Dual-Band Ka PLL LNB

The Norsat 9500HBCF Dual Ka-Band PLL LNB offers superior LO stability and gain flatness allowing users to reliably receive a narrower band transmission from Ka satellite networks. The versatile 9500HBCF series LNB input frequency is 19.2 to 21.2 GHz in two sub-bands, LO Band-1: 18.25, Band-2: 19.25 GHz, Stability ±50kHz, Input WR-42 waveguide, Output: F-Type connector (75 ohm), 60 dB gain., IF Frequency: 950 to 1950. Additional frequencies are available in three separate ranges:

Norsat 9500HBCF Ka- LNB Frequency Bands

Ordering Guide

Norsat 9500HBCF LNB Ordering Information

Outline Dimension Drawing

Norsat 9500HBCF Mechanical Drawing

Technical Specifications

KEY SPECIFICATIONS
Product Family	9000 Series
Band	Ka-Band
LO Type	PLL
# of onboard LOs	Dual-band
LO Stability	+/- 50 kHz
Noise Figure	1.6 - 1.8 dB
Input Frequency - Band 1	Ka-Band: 19.20 - 20.20 GHz
Input Frequency - Band 2	Ka-Band: 20.20 - 21.20 GHz
Output Frequency 1	L-Band: 950 - 1950 MHz
Output Frequency 2	L-Band: 950 - 1950 MHz
RF
LO Frequency 1	18.25 GHz
LO Frequency 2	19.25 GHz
Control Signal 1	13 V
Control Signal 2	18 V
Phase Noise @ 1KHz offset	-70 dBc/Hz
Phase Noise @ 10KHz offset	-78 dBc/Hz
Phase Noise @ 100KHz offset	-95 dBc/Hz
Conversion Gain	60 dB typ
Input VSWR	2.5 : 1
Output VSWR	2.5 : 1
Output P1dB compression point	5 dBm
ELECTRICAL
Power Requirements	12 - 24 V
Current Drain	400 mA
INTERFACE
RF Input Connector	WR-42 waveguide grooved
RF Output Connector	F-75 Ohm
ENVIRONMENTAL
Temperature - Operational	-40 to +60°C
Temperature - Storage	-40 to +80°C
PHYSICAL
Dimensions (L x W x H)	118 x 60 x 45 mm
Weight	400 g
