Norsat 9000LAN Ka-Band (18.2 - 19.2 GHz) DRO LNB (Type-N)
$286.00
SKU
NST-9000LAN
Norsat 9000LAN Ka-Band (18.2 - 19.2 GHz) DRO LNB (Type-N) is available to buy in increments of 1
Norsat 9000LAN Ka-Band DRO LNB
Norsat’s Low Noise Blocks (LNBs) provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard Ka-Band LNBs are backed by a 3 year warranty and nearly forty years of experience as the industry’s leading provider of high performance LNBs. 9000L Series.
Local oscillator frequency: 17.25 GHz
Noise Figure: 1.5 dB
KEY SPECIFICATIONS |
|
| Product Family | 9000 Series |
| Band | Ka-Band |
| LO Type | DRO |
| # of onboard LOs | Single-band |
| LO Stability | +/- 2 MHz |
| Noise Figure | 1.5 dB |
| Input Frequency - Band 1 | Ka-Band: 18.20 - 19.20 GHz |
| Output Frequency 1 | L-Band: 950 - 1950 MHz |
RF SPECIFICATIONS |
|
| LO Frequency 1 | 17.25 GHz |
| Phase Noise @ 1KHz offset | -60 dBc/Hz |
| Phase Noise @ 10KHz offset | -75 dBc/Hz |
| Phase Noise @ 100KHz offset | -95 dBc/Hz |
| Conversion Gain | 60 dB typ |
| Input VSWR | 2.5 : 1 |
| Output VSWR | 2.5 : 1 |
| Output P1dB compression point | 5 dBm |
| Gain Flatness Ripple | ≤ 5 dB p-p |
ELECTRICAL SPECIFICATIONS |
|
| Power Requirements | 12 - 24 V |
| Current Drain | 200 mA |
INTERFACE SPECIFICATIONS |
|
| RF Input Connector | WR-42 waveguide grooved |
| RF Output Connector | Type-N 50 Ohm |
ENVIRONMENTAL SPECIFICATIONS |
|
| Temperature - Operational | -30 to +60°C |
| Temperature - Storage | -40 to +80°C |
PHYSICAL SPECIFICATIONS |
|
| Dimensions (L x W x H) | 111 x 42 x 42 mm |
| Weight | 300 g |
Ka-Band Satellite service reception, Commercial TVRO, Broadband Services
