Norsat International 9000HA-2 Compact Ka-Band PLL LNB 18.20- 19.20 GHz
Ka-Band Frequency range from: 18.20 to 19.20 GHz, L.O. Stability: ±40.0 kHz , RF Output: F-connector or N-type, 1.3 dB Noise Figure
9000HA-2 Single-Band Ka PLL LNB
The Norsat 9000HA-2 series Ka-Band Compact PLL Low Noise Block Converter provides exceptional RF performance over Ka-Band satellite frequencies ranging from 18.20 to 19.20 GHz. The 9000HA-2 LNB features a superbly stable local oscillator that delivers ±40 kHz (2 ppm) L.O. stability. L-Band (950 to 1950 MHz) RF output configuration is provided via either a 50-ohm type-N female connector, or an F-connector. Ka-Band RF frequency input is accomplished with a precision grooved WR42 waveguide flange.
The 9000 series Ka-Band LNBs are compatible with all Ka VSAT and Earth Station antennas, in prime focus or offset feed configurations.
Local oscillator frequency: 17.25 GHz
Noise Figure: 1.3 dB
Norsat 9000HA-2 Series LNB Ordering Information
Outline Diagram
KEY SPECIFICATIONS |
|
| Product Family | 9000 Series |
| Band | Ka-Band |
| LO Type | PLL |
| # of onboard LOs | Single-band |
| LO Stability | +/- 60 kHz |
| Noise Figure | 1.5dB |
| Input Frequency - Band 1 | Ka-Band: 18.20 - 19.20 GHz |
| Output Frequency 1 | L-Band: 950 - 1950 MHz |
RF SPECIFICATIONS |
|
| LO Frequency 1 | 17.25 GHz |
| Phase Noise @ 1KHz offset | -75 dBc/Hz |
| Phase Noise @ 10KHz offset | -80 dBc/Hz |
| Phase Noise @ 100KHz offset | -100 dBc/Hz |
| Conversion Gain | 55 dB typ |
| Gain Variation over operating band | 4.0 dB p-p |
| Gain Variation over temperature | 5 dB max (-40°C to +60°C) |
| Input VSWR | 2.2 : 1 |
| Output VSWR | 2.0 : 1 |
| Output P1dB compression point | 3 dBm |
ELECTRICAL SPECIFICATIONS |
|
| Power Requirements | 15 - 24 V |
| Current Drain | 160 mA |
INTERFACE SPECIFICATIONS |
|
| RF Input Connector | WR-42 waveguide grooved |
| RF Output Connector | F-25 Ohm |
M & C SPECIFICATIONS |
|
| LED Indicators | None |
ENVIRONMENTAL SPECIFICATIONS |
|
| Temperature - Operational | -40 to +60°C |
PHYSICAL SPECIFICATIONS |
|
| Dimensions (L x W x H) | 111 x 42 x 42 mm |
| Weight | 350 g |
Ka-Band Earth Station Antennas, VSAT Network Systems, Inmarsat Global Express, O3B Terminals
