Norsat 1008XD-2 Single-Band (10.70-11.80 GHz) Externally Referenced Ku-Band VSAT LNB
Externally Referenced, Single-band Ku- 10.70-11.80 GHz, L.O. Frequency: 9.75 GHz, RF Output: F-Connector
The Norsat 1008XD-2 LNB provides single-band reception Ku frequencies from 10.70-11.80 GHz. The 1008XD-2 series utilizes a 75 Ohm F-connector for RF output and offers a local oscillator frequency of 9.75 GHz. This LNB features a noise figure rating of .8 dBm and comes standard with a WR75 waveguide input.
1008XD-2 Ordering Information
Outline Diagram
Installation Configuration
TYPICAL SPECIFICATIONS
Noise Figure 0.8 dBm
LO Stability ± Phase Locked to external reference
LO Phase Noise -75 dBc at 1 kHz
-85 dBc at 10 kHz
-95 dBc at 100 kHz
Gain 55 dB
P1dB +6 dBm
DC Power 18 V
Current 300 mA
Input Waveguide WR-75
Output F-connector (75 ohm)
N (Optional) (50 ohm)
Dimensions 150 x 42 x 40 (L x W x H)
Weight 300 g
Operating Temperature -40 - +60'C
FREQUENCY BANDS AVAILABLE
Frequency Band L 10.7 ~ 11.8 GHz
LO Frequency 9.75 GHz
H 10.75 GHz
IF Frequency 950 ~ 1950 MHz
Single-Band Ku-Band Satellite Reception
