Quintech Nexus-R RBM High Power Blocking Bi-Directional RF Matrix

The Quintech NEXUS-R 32X32 is a passive, bidirectional, blocking matrix switching system that provides a complete 32x32 matrix in a single 12 RU box. The use of low-loss miniature switching relays minimizes any effect on signals passing through the matrix. The unit uses latching relays that will retain the RF path in the event of power failure. All channels can be switched in 30 milliseconds. It features broadband operation from DC to 2.8 GHz and is perfect for testing wireless communication technologies such as LTE, 4G, and WiMax. All active components, including RF matrix cards and power supply, are field replaceable. Multiple modules can be combined to create larger matrices.

Nexus-R Features

 Latching relays ensure cross points remain connected upon loss of power.

 All active components, including RF matrix cards and power supply, are field replaceable.

 Multiple modules can be combined to create larger matrices.
