Quintech Nexus-L Full Fan-out Bi-directional RF Matrix
700 to 3000 Mhz, Passive Bi-directional, Partial Blocking
Nexus-L LTE 4G Bi-directional RF Matrix
This product has reached end of life and is no longer available. Please contact us for a compatible replacment solution from Quintech.
The Quintech NEXUS-L Series is a passive full fan out matrix switch which allows any of the inputs to be routed to any or all outputs. The operating frequency range of the switch covers 700 Mhz to 3000 Ghz. It is perfect for use in LTE, Wimax and 4G test applications. It automates test labs by replacing cumbersome patch panels and can be controlled easily via the front panel or remotely via a web browser interface. The basic configuration for the NEXUS Series is 16x16 or 32x32 switch which can be easily expanded to larger configurations. TheNEXUS Series meets strict specifications required in a lab environment to ensure no signal degradation.
Quintech Nexus-L Typical System Testing Configuration Diagram
Nexus-L Features
Designed specifically for use in LTE, WiMax and 4G test applications
Operating frequency range covers 700MHz to 3000Ghz
Automated testing process by replacing cumbersome patch panels
High performance to meet signal specifications in a test lab environment
LTE, Wimax and 4G test applications
