Intellian Technologies Americas TVRO PLL LNB
Standard on all Intellian Internet VSAT systems
Global PLL LNB
The Intellian Global Maritime PLL LNB provides maritime VSAT users seamless receive coverage throughout the world without the need to manually switch and change out LNB's.
Designed and manufactured by Intellian's in-house engineering, the All-Americas LNB combines two circular polarized LNB receivers into one device to ensure seamless and uninterrupted satellite TV service across multiple satellite coverage areas. With the press of a remote control button on the Antenna Control Unit, boaters can switch between DIRECTV, DISH Network or ExpressVu in North America and DIRECTV Latin in Central and South America.
Offering affordable and flawless access to the greatest number of channels at sea, Intellian's new All-Americas LNB presents commercial and recreational boaters with a convenient, continuous satellite TV solution for optimum entertainment throughout the Western Hemisphere.
Characteristics |
LOW BAND |
HIGH BAND |
Input Frequency | 11.45GHz ~ 12.20GHz | 12.20GHz ~ 12.75GHz |
Local Frequency | 10.5GHz ±1MHz (@ 25ºC ) | 11.25GHz ±1MHz (@ 25ºC ) |
Local Stability | ±2MHz ( -30ºC to +60ºC ) | ±2MHz ( -30ºC to +60ºC ) |
Output Frequency Range | 950MHz ~ 1700MHz | 950MHz ~ 1450MHz |
Noise Figure ( @ 25ºC ) | 0.8 dB Typ ( 1.1dB Max ) | |
Conversion Gain | 55 dB Typ | |
Gain Ripple | 1.0 dB p-p ( @ per channel ) | |
Gain Flatness | 6.0 dB p-p | |
Output VSWR | 2.5 : 1 Typ | |
Output Impedance | 75 Ohms | |
Output Connector | Two Output F - female Connector | |
Crosspol Discrimination | > 25 dB | |
Image Rejection | > 40 dBc | |
Phase Noise | -50 dBc / Hz ( @ 1kHz ) | |
-77 dBc / Hz ( @ 10kHz ) | ||
-95 dBc / Hz ( @ 100kHz ) | ||
LNB Supply Voltage & Control Signals |
- RHCP : 11.5 V to 14.0 V ( 13.0 VDC Typ. ) | |
- LHCP : 16.0 V to 19.0 V ( 18.0 VDC Typ. ) | ||
- Continuous 22kHz, 0.6±0.2 Vp-p for High Band Selection | ||
Current Consumption | 300mA Max. | |
Operating Temperature | -30ºC to +60ºC | |
Storge Temperature | -40ºC to +80ºC | |
Relative Humidity | 0% to 95% RH | |
Weight | 160g |
Seamless reception of DIRECTV, DISH Network or ExpressVu in North America and DIRECTV Latin in Central and South America.
