CPI SAT X-Band Antenna Mounted SSPAs- 50, 100, 125, 200W

X-Band 200, 125, 100, 50 Watt SSPAs

The CPI SAT (formerly GD Satcom Technologies & Prodelin) X-Band Compact Antenna Mounted SSPA's offer output powers of 50, 100, 125, or 200 watts across the standard 7.90 to 8.40 GHz satellite uplink band. Housed in a compact weatherproof enclosure, the amplifiers can be mounted in an antenna hub or outdoors in applications where it is desirable to reduce cable losses by mounting the SSPA close to the antenna.

Built-In Monitor & Control

These CPI amplifiers feature a microprocessor-based M&C system that facilitates easy setup and control.

Features

• 50/100/125/200 W saturated output power
• 70 dB gain
• Built-in monitor and control
• Temperature-compensated gain from -40 to +50 °C
• Serial interface (RS-232/-422/-485)
• Output isolator for high load VSWR protection
• 20 dB range digital gain adjustment
• RF output sample port (-40 dBc)
• Output power monitor
• Extremely light weight
• nominally 36 lb (16 kg)
• Mounts on small VSAT antennas
