AVL Technologies 1212KFD 1.2M Global Mobile Fly Drive Antenna System

GD Satcom Technologies 2125 1.2M Mobile VSAT Antenna

CPI SAT Model 2125 1.2M Mobile Vehicle Mounted VSAT System

Winegard WX1200 Motorized Auto-acquire VSAT Antenna

Winegard WX1200 1.2M Roof Mounted Auto Pointing VSAT Antenna System

Be the first to review this product

SKU

1212-KFD

AVL Technologies 1212KFD 1.2M Global Mobile Fly Drive Antenna System is available to buy in increments of 1

Ultra lightweight, carbon fiber reflector panels, Ku-band, vehicle mounted fly and drive system

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

1212KFD Compact Global SNG Internet VSAT

AVL Technologies 1212KFD is a compact, lightweight, motorized fly and drive satellite antenna system that's extremely portable and offers quick deployment in less than 10 minutes. 1212KFD is a Ku-Band system that's compatible with all popular satellite modems including iDirect Evolution series X5, X3 and X7.

Versatile

This fly and drive satellite system system is capable of being mounted on most vehicles. Apporved for use on Eutelsat, Intelsat, PanAmSat, FCC, Loral Skynet. Key features of the 1212 system include a precision segmented carbon fiber reflector, 400 degree azimuth range, integrated GPS system for easy auto pointing and level sensors for accommodating steep inclined surfaces.

avl technologies flyaway antenna 1ru power supply

Technical Specifications

1212KFD Specifications
Reflector	1.2 meter, AvL 4-piece Carbon-fiber
Feed	Mode-matched with Rotary Joint
Optics	Offset, Prime Focus, .8 f/d
Drive System	Patented Roto-Lok® Positioner
Mount Geometry	Elevation over Azimuth
Polarization	Rotation of Feed
Electrical RF
Frequency Range Receive Transmit	10.95-12.75 GHz 14.0-14.5 GHz
Gain (Midband) Receive Transmit	41.7 dBi 43.2 dBi
VSWR Receive Transmit	1.30:1 1.30:1
Beamwidth (degrees) -3 dB Receive Transmit -10 dB Receive Transmit	1.3 1.2 2.4 2.0
First Sidelobe Level (Typical) &nbps; Receive Transmit	-22 dB -25 dB
Antenna Noise Temperature	43° K at 30° Elevation
Polarization	Linear Orthogonal Standard, Optional Co-pol
Power Handling Capability	0.5KW per port
Cross-Pol Isolation On-Axis (minimum) Receive Transmit Off-Axis (within 1 dB BW) Receive Transmit Off-Axis (peak) Receive Transmit	35 dB 35 dB 30 dB 32 dB 22 dB 25 dB
Feed Port Isolation - TX to RX	75 dB
Satellite System Compliance	Eutelsat, Intelsat, PanAmSat, FCC, Loral Skynet
Controllers
Standard	Three-axis Jog Control & Display with Auto -stow
Optional Upgrades
Semi-automatic Operation	Drive to calculated position based on operator entered vehicle location, heading, p lus satellite (longitude or listed)
Automatic Operation	Drive to calculated position based on auto GPS and Flux- Gate Compass data and satellite peaking with LNB signal
Auto -acquisition	One-button acquisition of selected satellite including peaking and optimization of cross-pol (certified for autocommissioning on select services)
Size	Two Rack Units for Semi-automatic & Automatic Controllers Single Rack Unit for Auto-acquisition
Input Power	110/240 VAC, 1 ph, 50/60 Hz, 6/3A peak, 1A continuous
Mechanical
Az/El Drive System	Patented Roto-Lok® Cable Drive System
Polarization Drive System	Feed rotated by Non back-driving Worm Gear
Travel Azimuth Elevation Mechanical Electrical Polarization	400° True elevation readout from calibrated inclinometer 0° to 90° of reflector boresight Standard limits at 5° to 65° (CE Approval) or 5° to 90° ±95° for 2-port and 3-port Feeds ±50° for 2-port Wideband and 4-port feeds
Speed Slewing/Deploying Peaking	2°/second 0.2°/second
Motors	24V DC Variable Speed, Constant Torque
RF Interface HPA Mounting Axis Transition Waveguide Coax	Feed Boom, Inside Vehicle, or Separate Rotary Joint for Az, Flexible waveguide for El & Pol WR 75 Cover Flange at Pallet Interface Point RG59 with Type-N at Pallet Interface Point
Electrical Interface	10 ft. (3 m) Removable Cables for Controller
Manual Drive	Handcrank on Az and El Axii, Leads from 12VDC Pol Motor
Shipping Configuration
Main Pallet/Container with Positioner	105 lbs. (48 kg.), 59 x 25 x 21 in (150 x 64 x 53 cm)
Reflector Panel Container	55 lbs. (25 kg.), 29 x 29 x 27 in (74 x 74 x 69 cm)
Feed & Vehicle Attachment Components	100 lbs. (45 kg.), 59 x 25 x 21 in (150 x 64 x 53 cm)
Environmental
Wind Survival Deployed Stowed Operational	75 mph (121 kmph) 100 mph (161 kmph) 45 mph (72 kmph), Gusts to 60 mph (97 kmph)
Pointing Loss in Wind 20 mph (32 kmph) 30 Gusting to 45 mph (48 to 72 kmph)	0.2 dB, 0.15 degrees Typical 0.8 dB, 0.30 degrees Typical
Temperature Operational Survival	+5° to 125°F (-15° to 52°C) -40° to 140°F (-40° to 60°C)
