Novra S75CA DVB-CI Satellite Data Receiver
Receiving Frequency: 950 to 2150 MHz, - RF Input Connector: F-Type, 75 ohms, Symbol Rate: 1.5 to 45 Msps, LNB Supply Voltage: Selectable 13V, 18V, 21V or Off
Novra S75CA DVB-CI Receiver
The Novra S75CA provides all the functions and features of the S75+ and S75-Pro receivers, plus it adds a DVB-Compliant conditional access Common Interface (DVB-CI) slot. The inclusion of the DVB-CI slot provides a cost-effective means to provide compatibility with the vast majority of DVB conditional access systems. The S75CA is ideally suited as a video aggregation point for your IPTV network where distribution over LAN is desired and the content is scrambled with a DVB conditional access system. The S75CA is typically deployed along side the S75-Pro into head-end networks such as hotel or cruise ship infotainment, IPTV service, or cable TV service head ends.
Applications
The Novra S75CA is perfectly suited for consumer or small-medium enterprise use, delivering IP-based applications like IPTV, weather imaging and data, distance education, digital signage, file distribution, and Internet over satellite to a single computer or to a network of computers.
Features
- Compatible with TCP/IP Protocol Suite
- DVB Compliant
- 55 Mbps Sustained Throughput
- RJ45 10/100 Base-T Ethernet Interface
- Application Transparent
- Small Footprint
- IGMP
- Exceptional Flexibility. Through optional firmware loads, the S75 will support delivery of Broadcast TV services.
Designed for datacasting and video applications over ATSC broadcast signals (ground-based digital TV channels) with CAS.
