Norsat 9500HCDF Dual Ka-Band (20.2-22.2 GHz) PLL LNB F-Type ±50 kHz
$1,859.00
SKU
NST-9500HCDF-1
Norsat 9500HCDF Dual Ka-Band (20.2-22.2 GHz) PLL LNB F-Type ±50 kHz is available to buy in increments of 1
Dual Ka (20.2-22.2 GHz) PLL, F-Type 75 Ohm, Stability: ±50 kHz
9500HCDF Dual-Band Ka PLL LNB
The Norsat 9500HCDF Dual Ka-Band PLL LNB offers superior LO stability and gain flatness allowing users to reliably receive a narrower band transmission from Ka satellite networks. The versatile 9500HCDF series LNB input frequency is 20.2 to 22.2 GHz in two sub-bands, LO Band-1: 19.25, Band-2: 20.25 GHz, Stability ±50kHz, Input WR-42 waveguide, Output: F-Type connector (75 ohm), 60 dB gain., IF Frequency: 950 to 1950. Additional frequencies are available in three separate ranges:
Ordering Guide
Outline Dimension Drawing
KEY SPECIFICATIONS |
|
| Product Family | 9000 Series |
| Band | Ka-Band |
| LO Type | PLL |
| # of onboard LOs | Dual-band |
| LO Stability | +/- 50 kHz |
| Noise Figure | 1.6 - 1.8 dB |
| Input Frequency - Band 1 | Ka-Band: 20.20 - 21.20 GHz |
| Input Frequency - Band 2 | Ka-Band: 21.20 - 22.20 GHz |
| Output Frequency 1 | L-Band: 950 - 1950 MHz |
| Output Frequency 2 | L-Band: 950 - 1950 MHz |
RF |
|
| LO Frequency 1 | 19.25 GHz |
| LO Frequency 2 | 20.25 GHz |
| Control Signal 1 | 13 V |
| Control Signal 2 | 18 V |
| Phase Noise @ 1KHz offset | -70 dBc/Hz |
| Phase Noise @ 10KHz offset | -78 dBc/Hz |
| Phase Noise @ 100KHz offset | -95 dBc/Hz |
| Conversion Gain | 60 dB typ |
| Input VSWR | 2.5 : 1 |
| Output VSWR | 2.5 : 1 |
| Output P1dB compression point | 5 dBm |
ELECTRICAL |
|
| Power Requirements | 12 - 24 V |
| Current Drain | 400 mA |
INTERFACE |
|
| RF Input Connector | WR-42 waveguide grooved |
| RF Output Connector | F-75 Ohm |
ENVIRONMENTAL |
|
| Temperature - Operational | -40 to +60°C |
| Temperature - Storage | -40 to +80°C |
PHYSICAL |
|
| Dimensions (L x W x H) | 118 x 60 x 45 mm |
| Weight | 400 g |
Use on all commercial and government Ka antennas including VSAT, Fixed Earth Stations, Mobile and Maritime terminals
