Norsat 8000RIF Series DRO C-Band (3.4 to 4.2 GHz) Digital LNB
$180.00
SKU
NST-8000RIF
Norsat 8000RIF Series DRO C-Band (3.4 to 4.2 GHz) Digital LNB is available to buy in increments of 1
C-Band- 3.40 to 4.20 GHz, 5.75 GHz L.O. Frequency, Output: 950 to 1450 MHz
8000RIF C-Band DRO
The Norsat 8000RIF Series C-Band LNB has a local oscillator frequency of 5.75 GHz and operates from 3.40 to 4.20 GHz. The 8000RIF LNB is available with a 35K noise temperature configuration. This DRO Norsat C-Band LNB has a CPR229 waveguide input and offers Local Oscillator stability ranges of ±500 kHz. Type-F connector output.
Norsat 8000RIF Ordering Information
Terrestrial Interference Graph
Outline Diagram
KEY SPECIFICATIONS |
|
| Product Family | 8000 Series |
| Band | C-Band |
| LO Type | DRO |
| # of onboard LOs | Single-band |
| LO Stability | +/- 500 kHz |
| Noise Figure | 35 K |
| Input Frequency - Band 1 | C-Band: 3.625 - 4.80 GHz |
| Output Frequency 1 | L-Band: 950 - 2125 MHz |
RF SPECIFICATIONS |
|
| LO Frequency 1 | 5.75 GHz |
| Phase Noise @ 1KHz offset | -65 dBc/Hz |
| Phase Noise @ 10KHz offset | -80 dBc/Hz |
| Phase Noise @ 100KHz offset | -95 dBc/Hz |
| Conversion Gain | 62 dB typ |
| Input VSWR | 2.0 : 1 |
| Output VSWR | 2.2 : 1 |
| Output P1dB compression point | 5 dBm |
ELECTRICAL SPECIFICATIONS |
|
| Power Requirements | 12 - 24 V |
| Current Drain | 250 mA |
INTERFACE SPECIFICATIONS |
|
| RF Input Connector | CPR 229G waveguide grooved |
| RF Output Connector | F-75 Ohm |
M & C SPECIFICATIONS |
|
| LED Indicators | None |
ENVIRONMENTAL SPECIFICATIONS |
|
| Temperature - Operational | -40 to +60°C |
| Temperature - Storage | -50 to +70°C |
PHYSICAL SPECIFICATIONS |
|
| Dimensions (L x W x H) | 180 x 100 x 70 mm |
| Weight | 450 g |
VSAT, Tx/Rx, TVRO, Maritime
