Norsat 5150IN INSAT C-Band PLL LNB +/-150 kHz N-Type

Norsat 5250RN C-Band PLL LNB +/-250 kHz N-Type

Norsat 5150R Series C-Band PLL LNB (3.4 - 4.2 GHz) with Interference Rejection

Be the first to review this product

$176.00

SKU

NST-5150IN

Norsat 5150IN INSAT C-Band PLL LNB +/-150 kHz N-Type is available to buy in increments of 1

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

NORSAT 5150IN INSAT C-BAND PLL LNB +/-150 kHz

Ideal for DVB (Digital Video Broadcast), VSAT Broadband, Military Satcom, Point-of-Sale, and Oil and Gas applications where built-in interference rejection is required

Input Frequency: 4.5 - 4.8 GHz
L.O. Stability: +/-150 kHz
Noise Figure: 15K typical
Output Connector: N-Type Female
L.O. Frequency: 5.95 GHz
Conversion Gain: 62 dB typical
Output frequency (MHz) 1150 – 1450 MHz

Norsat 5150IN INSAT C-Band PLL LNB Ordering Configuration

Technical Specifications

TYPICAL SPECIFICATIONS

L.O. stability ±150 kHz, ±250 kHz
Noise temperature 15 K typ., 30 K max
Phase noise -65 dBc/Hz @ 1 kHz offset -80 dBc/Hz @ 10 kHz offset -95 dBc/Hz @ 100 kHz offset
Input VSWR & Output VSWR 2.5:1
Conversion gain 62 dB typical 55 dB min 70 dB max
Output P1dB 5 dBm
Power requirements 12 - 24V DC supplied through center conductor of IF cable
Current drain 250 mA
Input Waveguide CPR 229G
Dimensions 190 (L) x 115 (W) x 78 (H) mm (7.1 x 4.0 x 2.8 in)
Weight 580 g / 20.5 oz
Temperature Range -40°C to +60°C

Applications

Ideal for DBV (Digital Broadcast Video), VSAT Broadband, Military Satcom, Point-of-Sale, and Oil and Gas applications where interference rejection is required.
