Norsat 1008XHBF Ku-Band (12.25 - 12.75 GHz) Compact Ext Reference LNB (F-Connector)
PLL, Externally Referenced, 12.25- 12.75 GHz, L.O. Frequency: 11.30, RF Output: F Connector
1008XHBF External Reference Ku-Band LNB
The Norsat 1008XHBF Series Ku-Band LNB provides excellent performance for Ku Satellite reception from 12.25- 12.75 GHz. The 10008XHBF LNB features a Type F connector RF output with a local oscillator frequency of 11.30 GHz and noise figure rating of .8 dBm. WR75 waveguide RF input, Phase Locked to External Reference.
Norsat 1000XH Series Ordering Information
Outline Diagram
TYPICAL SPECIFICATIONS
Noise Figure 0.7 to 0.9 dB depending on model
L.O. stability Phase Locked to External Reference
Gain Flatness (-40°C to +60°C) 1.5dBp-p @ over 27 MHz
4dBp-p @ over 500 MHz
Gain Variation @ Fixed Freq. 6 dBp-p max (-40°C to +60°C)
Phase noise -75 dBc / Hz at 1 kHz (SSB) -85 dBc / Hz at 10 kHz -95 dBc / Hz at 100 kHz
Input VSWR 2.0 : 1
Output VSWR 2.0 : 1
Conversion gain 60 dB
Output P1dB 8 dBm
Power requirements +15 to +24 V supplied through center conductor of IF cable
Current drain 200 mA
Input Waveguide WR75
Dimensions 110 (L) x 42 (W) x 42 (H) mm (4.3 x 1.7 x 1.7 in)
Weight 300g / 10.6 oz
External Ref Frequency 10MHz (sine-wave), -10 to 0 dBm
Temperature Range -40C to +60C
Frequency Bands Available
|
Typical service |
1000XHA |
1000XHB |
1000XHC |
|
Input frequency (GHz) |
11.70 - 12.20 |
12.25 - 12.75 |
10.95 - 11.70 |
|
L.O. frequency (GHz) |
10.75 |
11.30 |
10.00 |
|
Output frequency (MHz) |
950 - 1450 |
950 - 1450 |
950 - 1700 |
Ku-Band Satellite Signal Reception, TVRO, Broadband Internet Systems
