Norsat 1008XGF-2 Ku-Band (12.20- 12.70 GHz) PLL Ext Reference LNB F-connector
$616.00
SKU
NST-1008XGF-2
Norsat 1008XGF-2 Ku-Band (12.20- 12.70 GHz) PLL Ext Reference LNB F-connector is available to buy in increments of 1
PLL, Externally Referenced, 12.20 - 12.70 GHz, L.O. Frequency: 11.25, RF Output: F-connector
The Norsat 1008XGF-2 Series Ku-Band LNB provides excellent performance for Ku Satellite reception in frequencies ranging from 12.20-12.70 GHz. The 1008XGF-2 LNB features a 75 Ohm F-connector RF output with a local oscillator frequency of 11.25 GHz and noise figure rating of .8 dBm. WR75 waveguide RF input, Phase Locked to External Reference.
Ordering Information
Outline Diagram
KEY SPECIFICATIONS | |
|---|---|
| Band | Ku-Band |
| Input Frequency Band 1 | Ku-Band: 12.20 - 12.70 GHz |
| Lo Stability | Phase Locked to External Reference at 10MHz |
| Lo Type | External |
| Noise Figure | 0.8 dB |
| Output Frequency 1 | L-Band: 950 - 2050 MHz |
| Product Family | 1008XGF-2 |
RF | |
|---|---|
| Conversion Gain | 60 dB typ |
| Lo Frequency 1 | 11.25 GHz |
INTERFACE | |
|---|---|
| RF Input Connector | WR-75 waveguide grooved |
| RF Output Connector | F-connector 75 Ohm |
ENVIRONMENTAL | |
|---|---|
| Humidity | 0 - 95% |
| Temperature Operational | -40 to +60°C |
PHYSICAL | |
|---|---|
| Dimensions (LxWxH) | 128 x 60 x 40 mm |
Ku-Band Satellite Signal Reception, TVRO, Broadband Internet Systems
