HZ930 Satellite Receiver and Deconcentrator

HZ930 Satellite Receiver and Deconcentrator

The HZ930 satellite receiver and demultiplexer displays Newtec’s vast understanding of the challenge of distributing different television multiplexes to a number of remote terrestrial transmission sites over satellite.

Transparent and efficient transport of content are key elements for each player in the primary distribution of terrestrial and mobile TV.  The Horizon Series makes use of the innovative proprietary concentration technology by Newtec. This technology combines up to 8 MPEG Transport streams into a single stream without changing their content. The resulting stream remains compatible with MPEG/DVB transmission equipment such as modulators or ATM interfaces.

Content Delivery Network

The HZ930 is installed at the receiving end of Newtec’s multiplexer solution.  The Newtec multiplexer –de-multiplexer solution guarantees the integrity of the initial Transport stream at the receiving end.  The output of the 930 is bit-by-bit identical to the signal transmitted by the play out center. This feature is essential in networks with strict synchronization requirements like SFN networks where adjacent towers are transmitting on the same frequency.

The HZ 930 supports both DVB-S and DVB-S2 modulation standards and allows de-concentration up to 4 ASI streams.  The mapping between the streams and the outputs is fully programmable, enabling the use of the HZ-930 as a matrix router to send Transport streams to various access points in a network.

A descrambling feature has been added to protect each stream individually against piracy.  Th 930 is easy to operate and monitor. All control and monitoring parameters are available locally on the front panel and remotely through a web interface. It is also possible to control or monitor the AZ930 via RMCP or SNMP.

Key Features

• Demodulates DVB-S or DVB-S2 signals

• Demultiplexes the bundled Transport streams into 4 individual ASI streams

• Fully transparent and efficient transport of content

• Compliant to SFN requirements

• Independent descrambling of each individual Transport stream

• Matrix routing of the Transport stream outputs

• Optional 10 MHz reference input/output

Main advantages

• Lower operational costs thanks to efficient use of transmission bandwidth

• Cost-effective and easy to implement technology compared to traditional multiplexer solutions

• Protection of the data content against unauthorized access by other parties.

Applications

1. Primary distribution of digital television- Digisat has engineered the perfect solution to increase the efficiency of satellite bandwidth usage. Transport streams from different broadcasters or intended for different regions can be bundled on the same satellite carrier. Cable head-ends and terrestrial/mobile TV remote transmitters can now benefit from optimized feeder links over satellite. Additionally this solution is fully compatible with SFN requirements and allows protecting the different Transport streams independently.

2. ASI networking and routing- The matrix routing function enables routing between the multiple inputs and the multiple outputs of the concentrator and deconcentrator devices.  In a cabled or wireless network, the combined Transport streams can be deconcentrated and the signals extracted individually in order to send the required transport streams to various access points in the network.
