CPI SAT X-Band 350W Outdoor Antenna Mounted SSPA DPX8350N

DPX8350N 350 Watt X-Band Amplifier

The CPI SAT (formerly GD Satcom Technologies & Prodelin) X-Band 350W Outdoor Antenna Mounted SSPA DPX8350N uses technology developed for ModuMAX amplifiers, this outdoor SSPA features a modular architecture with field- replaceable RF assemblies and offers an output power of 350 watts across the standard 7.90–8.40 GHz satellite uplink band. Housed in a weatherproof NEMA 4X enclosure, the amplifiers can be mounted in an antenna hub or outdoors in applications where it is desirable to reduce cable losses by mounting the SSPA close to the antenna.

M&C

Built for reliable, trouble-free service, the amplifiers incorporate a microprocessor-based monitor and control system.

Features

• Field-replaceable RF assemblies
• 350 Watt saturated output power
• Microprocessor-based monitor and control
• Serial interface (RS-232/-422/-485)
• Output isolator for high load VSWR protection
• 20 dB range digital gain adjustment
• RF output sample port
• External mute input
• Reflected power monitoring

Applications

• Stand-alone SSPA
• 1:1 and 1:2 redundant systems
• Government and Military systems

Options

• Block upconverter
• Operating Frequency: 7.90 to 8.40 GHz
