Agilis Satcom ALB128 8 Watt Compact Ku-Band Block Upconverter (BUC)
Fully adjustable gain settings, Phase Locked Oscillator, excellent for all Broadband VSAT applications
ALB128 8W Ku Block Upconverter
Agilis ALB128 Series 8 watt Ku-Band BUC (Block-Up Converter) is a highly cost-effective RF outdoor transmitter for satellite communication systems. The ALB128 8W BUC has very high output power linearity and works well from -40ºC up to 60ºC. The BUC also has a wide input voltage range which allows it to work from 18V to 60V. Agilis Ku-Band BUC is designed for high reliability operation in various applications such as flyaway antenna.
Simple Installation
The BUC also has the most complete M&C features in the industry. Easy to install, it is redundancy-ready and field-proven for any harsh operating environment. It is suitable for both data and voice communication operating in different modulation formats. Agilis Ku-Band BUC is a compact design that comprises of Upconverter, Solid State Power Amplifier, Phase Locked Oscillator and DC-DC power converter. It employs L-Band IF interface to the indoor unit.
Agilis ALB128 Ku-Band BUC is an ideal design suitable for broadband applications (such as DVB-RCS) in satellite IP networks.
Features
Operates over all Ku-Band frequencies
Direct antenna mounting
Extensive operating temperature range from -40C to +60C
Outstanding phase noise characteristics.
Maritime VSAT Systems and Networks, Mobile Satcom Terminals, Disaster Communications Restoral Services and more.
