Norsat International 9000LD Single-Band Ka (21.2 - 22.2 GHz) DRO LNB

Norsat 9000XB-4 Ka-Band Ext. Ref. LNB (19.2 - 20.2 GHz)

Norsat 9016XAEBE-3F Ka-Band Dual External Reference LNB

Norsat 9016XAEBE-3F Dual Ka-Band External Reference LNB F-Type

Be the first to review this product

$242.00

SKU

NST-9000LD

Norsat International 9000LD Single-Band Ka (21.2 - 22.2 GHz) DRO LNB is available to buy in increments of 1

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

9000LD Single-band Ka DRO LNB

The Norsat International 9000LD Ka-Band DRO Low Noise Block Down Converter (LNB) provides excellent RF performance over Ka-Band satellite frequencies ranging from 21.20 - 22.20 GHz. The 9000LD Series LNB features an extremely stable local oscillator that delivers ±2 MHz L.O. stability. L-Band 950 - 1950 MHz RF output configuration is provided via either a 50-ohm type-N female connector or an F-connector.

RF input: WR42

Local oscillator frequency: 20.25 GHz

Noise Figure: 1.5 dB

9000LD Frequency Configuration

9000LD Ordering Information

9000LD Outline Dimension Diagram

Technical Specifications

Noise figure 1.5 dB max.
L.O. stability ±2.0 MHz
Phase noise (SSB) max -60 dBc/Hz @1KHz -80 dBc/Hz @10KHz -100 dBc/Hz@100KHz
Gain 60 dB typ., 55 dB min. @ full frequency band
Output P1dB + 5 dBm min
DC Power +12V to +24V
DC Current 150 mA Input (waterproof)
WR-42 waveguide Output (waterproof) F-connector (75 ohm) N-connector (optional) (50 ohm)
Dimensions 111mm (L) x 42mm (W) x 42mm (H)
Weight 300 g
Operating Temperature -30 to + 60°C
Storage Temperature -40°C to +80°C

Applications

Ka Satellite service reception, TVRO, Broadband Services
