Norsat 9000LCF Ka-Band DRO LNB (20.2-21.2 GHz) Type-F
$242.00
SKU
NST-9000LCF
Norsat 9000LCF Ka-Band DRO LNB (20.2-21.2 GHz) Type-F is available to buy in increments of 1
9000LCF Ka-Band DRO LNB
The Norsat 9000LCF Ka-Band DRO Low Noise Block Down Converter (LNB) provides excellent RF performance over Ka satellite frequencies ranging from 20.20 - 21.20 GHz. The 9000LCF Series LNB features an extremely stable local oscillator that delivers ±2 MHz L.O. stability. L-Band 950 - 1950 MHz RF output configuration is provided via a 75 ohm Type-F female connector. RF frequency input is accomplished with a precision grooved WR42 waveguide flange.
Local oscillator frequency: 19.25 GHz
Noise Figure: 1.5 dB
- Noise figure 1.5 dB max.
- L.O. stability ±2.0 MHz
- Phase noise (SSB) max -60 dBc/Hz @1KHz -80 dBc/Hz @10KHz -100 dBc/Hz@100KHz
- Gain 60 dB typ., 55 dB min. @ full frequency band
- Output P1dB + 5 dBm min
- DC Power +12V to +24V
- DC Current 150 mA Input (waterproof)
- WR-42 waveguide Output (waterproof) F-connector (75 ohm) N-connector (optional) (50 ohm)
- Dimensions 111mm (L) x 42mm (W) x 42mm (H)
- Weight 300 g
- Operating Temperature -30 to + 60°C
- Storage Temperature -40°C to +80°C
VSAT applications, TVRO, Broadband Services
