Be the first to review this product

$1,474.00

SKU

Norsat 9000XBN-2

Norsat 9000XBN-2 Ext. Ref. Ka-Band Series LNB 19.20- 20.20 GHz Type-N Connector is available to buy in increments of 1

Ka-Band frequencies from 19.20 to 20.20 GHz, L.O. Stability: ±1.3 ppm , L-Band RF Output: Type-N Female connector, 1.3 dB Noise Figure

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

9000XBN-2 Ka-band Ext. Ref. LNB

The Norsat 9000XBN-2 Series Ka-Band Low Noise Block Converter is compatible with a wide range of Ka-band satellites and antennas including prime focus and offset reflectors. The 9000XBN-2 Ka-Band LNB operates from 19.20 to 20.20 GHz and features a highly stable local oscillator that's phase locked to external reference. L-Band RF output is 950 to 1950 MHz and RF output connector is a 50-ohm type-N female. Ka-Band RF frequency input is accomplished with a precision grooved WR42 waveguide flange.

Noise Figure: 1.3 dB

9000XBN-2 Ka-Band Frequencies and Local Oscillator Info:

Norsat 9000XBN-2 LNB Frequency Chart

Norsat 9000XBN-2 LNB Ordering Information

Outline Diagram

Technical Specifications

KEY SPECIFICATIONS
Product Family	9000 Series
Band	Ka-Band
LO Type	External
# of onboard LOs	Single-band
LO Stability	Phase Locked to External Reference at 10MHz
Noise Figure	1.5 dB
Input Frequency - Band 1	Ka-Band: 19.20 - 20.20 GHz
Output Frequency 1	L-Band: 950 - 1950 MHz

RF SPECIFICATIONS
LO Frequency 1	18.25 GHz
Phase Noise @ 100Hz offset	-65 dBc/Hz
Phase Noise @ 1KHz offset	-75 dBc/Hz
Phase Noise @ 10KHz offset	-80 dBc/Hz
Phase Noise @ 100KHz offset	-100 dBc/Hz
Conversion Gain	55 dBm
Gain Variation over operating band	4 dBm p-p over 1000MHz
Gain Variation over temperature	5 dBm max (-40°C to +60°C)
Input VSWR	2.0 : 1
Output VSWR	2.0 : 1
Output P1dB compression point	3 dBm

ELECTRICAL SPECIFICATIONS
Power Requirements	15 - 24 V
Current Drain	160 mA

INTERFACE SPECIFICATIONS
RF Input Connector	WR-42 waveguide grooved
RF Output Connector	N-50 Ohm

M & C SPECIFICATIONS
LED Indicators	None

ENVIRONMENTAL SPECIFICATIONS
Temperature - Operational	-40 to +60°C
Humidity	0 - 95%

PHYSICAL SPECIFICATIONS
Dimensions (L x W x H)	111 x 42 x 42 mm
Weight	350 g
