Agilis Satcom ALB190 40W C-Band Ultra Compact Outdoor BUC (Block Upconverter)

Agilis ALB190 25W Ultra Compact C-Band BUC (Block Upconverter)

Agilis Satcom ALB190 25W C-Band Ultra Compact Outdoor BUC (Block Upconverter)

Agilis Satcom ALB190 50W C-Band Ultra Compact Outdoor BUC (Block Upconverter)

Be the first to review this product

SKU

ALB190-40W-C

Agilis Satcom ALB190 40W C-Band Ultra Compact Outdoor BUC (Block Upconverter) is available to buy in increments of 1

Compact design for easy antenna mounting, Simple feed mounting

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

ALB190 40 Watt BUC C-Band

The Agilis Satcom ALB190 40W C-Band Ultra Compact Outdoor BUC (Block Upconverter) is an outdoor RF transmitter for satellite communication systems that's ideal for remote, flyaway, and other satcom systems that require lightweight RF equipment.

The ALB190 40 Watt Compact BUC is field proven under harsh environmental conditions, and can withstand temperatures ranging from -40ºC to +60ºC with up to 100% humidity. This small and lightweight BUC is designed to be mounted directly on the feed horn and this BUC has excellent efficiency consuming less than 250W.

Auto Sensing

The unit works on a wide range DC power supply of 38V to 60V. The BUC is able to work up to 60ºC with it's internal innovative and efficient thermal design. With a redundancy-ready feature, the unit can be easily configured to work in 1:1 redundant mode.
