Agilis Satcom AAV610 BUC and LNB Redundancy Control Unit System

AAV610 Redundant LNB Controller System

Agilis Satcom AAV610 provides LNB redundancy for satellite communications systems. The AAV610 has a built in power supply & reference signal, supports both C and Ku-Band LNBs,  supports programmable attenuation on each path to equalize the path gains, and redundant 180-230 VAC mains power supply.

Rugged Design

The Agilis LNB redundant controller system is field proven with many systems deployed worldwide. The Agilis RCU can withstand temperature from -40ºC to +60ºC up to 100% humidity.

Key Features

Provides power supply and reference signal to redundant LNB units

Power supply in 1:1 redundant mode is available

Supports C and Ku-Band LNBs

Built-in 1:1 extremely stable 10MHz OCXO (Optional)

10 MHz reference available in 1:1 redundant mode

Redundant 180-230 VAC power supply input

Fault indication by LED display King post / pole mount outdoor unit with IP65 rated

RS 232/ RS 485 serial and SNMP for remote Monitoring & Control

Form C contact closure outputs

Includes Field programmable firmware.
