SKU
PD-vBUC-Ku
Paradise Datacom GAN vBUC Ku-Band VSAT Block Upconverter is available to buy in increments of 1

Ku-Band power output of up to 40 Watts

GAN vBUC Ku-Band VSAT Block Upconverter

The next generation of High Power Density Block Up Converters has been unveiled at Teledyne Paradise Datacom. Powered by GaN technology, these converters are the most efficient in the Satcom Industry. GaN devices pack a high output power capability within a compact physical volume.


Thermal Efficiency

GaN devices make ideal power amplifiers at microwave frequencies because they can operate at much higher temperatures and work at much higher voltages than GaAs devices.


RF Performance

GaN devices also offer higher power efficiency and greater linear power capability. A wide range of monitor and control is standard and includes Legacy FSK protocol, Standard Paradise Datacom RS-485 and Ethernet support via UDP, SNMP, and an Internal Web Browser.


Complete Redundancy

The vBUC is available in 1:1 redundant configurations, 1:2 redundant configurations with the addition of a RCP2-1200 Redundant System Controller. Chain 1:1 redundancy is available with the use of a RCPD-1100 Dual Redundant Controller.

PARAMETER

MODEL NUMBER

NOTES

LIMITS

UNITS

Frequency Range

1

14.0 to 14.5

GHz



Output Power @: PSAT / Two-Tone PLINEAR (Typical / Guaranteed Minimum)

VBUCK40AAXXWXX

Gain 76 dB

PSAT / Two-Tone PLINEAR 46.0/43.0 (40/20)

dBm (W)

Power Requirements: Typical (Max) 48 VDC Input Current AC Input Power

VBUCK40AA_XWXX

@ Two-Tone PLINEAR 4.3 (4.8) 255 (285)

@ rated PSAT 5.5 (6.0) 325 (355)

A W

Newsgathering terminals, remote uplinks, SNG trucks, fixed VSAT sites
