ASC Signal 7.6m C & X-Band Low PIM Tx/Rx Earth Station Antenna
No field alignment at C or X-bands, Rugged aluminum and steel construction, 3 Year warranty on structural components
7.6M ESA C-Band / X-Band Satcom Antenna
The ASC Signal 7.6 meter earth station antenna provides high gain and exceptional pattern characteristics. The electrical performance and versatility provide the ability to configure the antenna with a choice of linearly polarized or circularly polarized 2-port or 4- port combining networks. This antenna features a computer-optimized dual reflector Gregorian system.
Tripod Mount
The 7.6M is capable of operation at C-, X-, Ku- and K- bands with the selection of feed and combiner systems. The versatile tripod mount, features 180 degree azimuth coverage in three contiguous 120 degree overlapping ranges, and 85o continuous elevation adjustment. This large range of adjustment provides non-critical foundation orientation, and the ability to view geostationary satellites, from horizon-to-horizon, from any location worldwide. The electrical performance and exceptional versatility provides the ability to configure the antenna with your choice of combining network. That versatility is provided at the time of initial purchase, as well as in the future, as your satellite communication requirements evolve.
High Gain
This antenna system is used worldwide in broadcast applications and high density data, voice and communications networks. The ASC Signal 7.6 meter earth station antenna features a computer optimized dual reflector Gregorian optics system and close-tolerance manufacturing techniques. This combination provides extremely accurate surface contour resulting in exceptionally high gain and closely controlled pattern characteristics. ASC Signal earth station antennas provide maximum durability with minimal maintenance.
Ideal for both C-Band and Military X-Band satellite communications system applications.
